Figure 30-29 Resistance and capacitance in an alternating-current (AC) circuit. In an AC circuit (A), unlike a direct-current circuit, the capacitor does not block current flow. The capacitor and resistance act to shift the phase of the AC current. Current changes lag behind voltage changes (B).
